12V Standard Module Battery

Product model of 12V Standard Module Battery

12.8V 100Ah LFP Lead Acid Replacement Battery

12.8V 100Ah LFP Lithium Replacement

Specification
Nominal Capacity: 100Ah
Operating Voltage: 8.4~14.6V
Charging current: ≤100A
Discharging current: ≤100A
Temperature: -20~60℃
Dimension: 329*172*217mm(±3mm)
Weight: 12.5Kg
Packaging: Plastic case
Protection: PCM/BMS(Customized available)

12.8V 20.4Ah LFP Lithium Replacement

Model NO.12.8V 20.4Ah LFP

Specification
Nominal Capacity: 20.4Ah
Operating Voltage: 8.4~14.6V
Charging current: ≤20A
Discharging current: ≤20A
Temperature: -20~60℃
Dimension: 181*77*171mm(±1mm)
Weight: 2.9Kg
Packaging: Plastic case
Protection: PCM/BMS(Customized available)

Product model table

Model NO.	Rated Capacity	Operation Voltage	Charging Current Max	Discharge Current Max	Energy	Dimension(mm)	Weight
Length	Width	Height
12.8V 50Ah LFP	50Ah	12.8V	50A	50A	640Wh	229±1mm	138±1mm	208±1mm	6.2Kg
12.8V 7.2Ah LFP	7.2Ah	12.8V	7A	9A	92.1Wh	229±1mm	138±1mm	208±1mm	6.2Kg
12.8V 74.8Ah LFP	74.8Ah	12.8V	75A	75A	957.44Wh	256±1mm	256±1mm	256±1mm	10Kg
6.4V 3.8Ah LFP	3.8Ah	6.4V	3.8A	5A	24.32Wh	70±1mm	47±1mm	101±1mm	0.3Kg
12.8V 47.6Ah LFP	47.6Ah	12.8V	47A	50A	609.28Wh	197±1mm	165±1mm	170±1mm	6.5Kg
12.8V 34Ah LFP	34Ah	12.8V	32A	32A	435.2Wh	193±1mm	132±1mm	168±1mm	4.7Kg
12.8V 10.8Ah LFP	10.8Ah	12.8V	10A	10A	138.24Wh	151±1mm	94±1mm	99±1mm	1.5Kg
12.8V 150Ah LFP	150Ah	12.8V	150A	150A	1920Wh	521±1mm	238±1mm	218±1mm	18Kg
12.8V 20.4Ah LFP	20.4Ah	12.8V	20A	20A	261.1Wh	181±1mm	77±1mm	171±1mm	2.9Kg
12.8V 100Ah LFP	100Ah	12.8V	100A	100A	1280Wh	329±3mm	172±3mm	217±3mm	12.5Kg

Model NO.	12.8V 50Ah LFP	12.8V 7.2Ah LFP	12.8V 74.8Ah LFP	6.4V 3.8Ah LFP	12.8V 47.6Ah LFP	12.8V 34Ah LFP	12.8V 10.8Ah LFP	12.8V 150Ah LFP	12.8V 20.4Ah LFP	12.8V 100Ah LFP
Rated Capacity	50Ah	7.2Ah	74.8Ah	3.8Ah	47.6Ah	34Ah	10.8Ah	150Ah	20.4Ah	100Ah
Operation Voltage	12.8V	12.8V	12.8V	6.4V	12.8V	12.8V	12.8V	12.8V	12.8V	12.8V
Charging Current Max	50A	7A	75A	3.8A	47A	32A	10A	150A	20A	100A
Discharge Current Max	50A	9A	75A	5A	50A	32A	10A	150A	20A	100A
Energy	640Wh	92.1Wh	957.44Wh	24.32Wh	609.28Wh	435.2Wh	138.24Wh	1920Wh	261.1Wh	1280Wh
Dimension(mm)	229±1mm	229±1mm	256±1mm	70±1mm	197±1mm	193±1mm	151±1mm	521±1mm	181±1mm	329±3mm
Weight	6.2Kg	6.2Kg	10Kg	0.3Kg	6.5Kg	4.7Kg	1.5Kg	18Kg	2.9Kg	12.5Kg

Contact Us

Characteristics and advantages of 12V Standard Module Battery

Product Features

• Widely used to replace many applications of lead-acid batteries.

• It has a long life,1.5 times the energy density of lead-acid batteries, and a long cycle life, 4-8 times of lead-acid batteries.

• It supports fast charging & discharging and saves the charging time greatly, the usage efficiency is up to 97%.

• It has wide applicability and supports the use of batteries in series.

Safe And Reliable

• Hardeware design and imported IC & MOSFET are used to ensure the safety and stable performance of lithium battery.

• Low internal resistance and flow force circuit design.

• IEC62133, UL, UN38.3 certified.

Super Long Life

• The initialcell performance, dynamic charge & discharge, high and low temperature characteristics,charge & discharge curves with very good consistency.

• The cycle life of lithium battery can reach more than 4000 times.

• Low power consumption design,long battery life.

Application: With the implementation of environmental protection and related national policies, the disadvantages of lead-acid batteries are also becoming more and more obvious. The technological level of lead-acid batteries has reached the limit, its service life, energy density, and environmental pollution all show the trend of being replaced by lithium batteries, so the lithium-ion batteries have greater potential.

characteristic: It has a wide range of applications, high temperature adaptability, and long battery life, the energy density is 1.5 times of lead-acid batteries, and the cycle life is 4-8 times of lead-acid batteries.Lithium battery supports fast charge & discharge and saves the charging time significantly, the using efficiency up to 97%.
