Agriculture Start Battery

Product model of Agriculture Start Battery

12.8V 20Ah LFP High Rate Automotive battery

Specification
Nominal Capacity: 20Ah
Operating Voltage: 8.4~14.5V
Charging current: ≤40A @25~45℃
Instant discharge current: ≤1000A/5S
Temperature: -20~60℃
Dimension: 180*165*76(±1mm）
Weight: 4Kg
Packaging: Plastic case
Protection: PCM(Customized available)

12.8V 10Ah LFP High Rate Agricultural Machinery Battery

Model NO.12.8V 10Ah LFP High Rate

Specification
Nominal Capacity: 10Ah
Operating Voltage: 8.4~14.5V
Charging current: ≤20A
MAX.Discharging current: ≤500A/5S
Temperature: -20~60℃
Dimension: 216*124*95.9(±1mm）
Weight: 2.5Kg
Packaging: Plastic case
Protection: PCM(Customized available)

Product model table

Model NO.	Rated Capacity	Operation Voltage	Charging Current Max	Discharge Current Max	Energy	Dimension(mm)	Weight
Length	Width	Height
12.8V 10Ah LFP High Rate	10Ah	12.8V	10A	10A	128Wh	216±1mm	124±1mm	95.9±1mm	2.5kg
12.8V 20Ah LFP High Rate	20Ah	12.8V	20A	20A	256Wh	180±1mm	165±1mm	76±1mm	4Kg

Model NO.	12.8V 10Ah LFP High Rate	12.8V 20Ah LFP High Rate
Rated Capacity	10Ah	20Ah
Operation Voltage	12.8V	12.8V
Charging Current Max	10A	20A
Discharge Current Max	10A	20A
Energy	128Wh	256Wh
Dimension(mm)	216±1mm	180±1mm
Weight	2.5kg	4Kg

Contact Us

Characteristics and advantages of Agriculture Start Battery

Product Features

• Widely used in agricultural machinery, tractors, automobiles, trucks, ships, diesel generators, forklifts, bulldozers and other construction machinery, to replace conventional lead-acid batteries, higher working temperature range and capacity retention rate.

• IP67 high protection level, adapt to a variety of harsh environments.

• The interior of the product is made of insulation and protective materials that meet RoHS and 94V0 fireproof grade. Heat dissipation design, safe and reliable.

• Tight internal structure design, strong anti-vibration ability.

Super Power

• Low internal resistance and main power circuit design.

• 30C ultra-high rate lithium iron phosphate battery.

• Certified by IEC62133,UL and UN38.3.

• Wider working temperature range, high power uninterrupted output.

Super Long Life

• High consistency of battery cells including the initial performance of the cell, the charge and discharge dynamics, the charge and discharge curves, and the high and low temperature characteristics.

• The cycle life of the product can reach more than 4000 times.

• Low power consumption and long standby time.

Application: Widely used in agricultural machinery, tractors, automobiles, trucks, ships, diesel generators, forklifts, bulldozers and other construction machinery, fully replace lead-acid batteries, can also be used for emergency start, light and portable.

Charateristics: High-protection and long-life lithium battery, internal wide working temperature range and IP68 high protection level make it still usable in harsh environments, superior performance, certified by IEC, UN, UL, etc;The built-in protection system comes with multiple protections.Safe and reliable.
