Model NO.12.8V 20Ah LFP High Rate
Specification
Nominal Capacity: 20Ah
Operating Voltage: 8.4~14.5V
Charging current: ≤40A @25~45℃
Instant discharge current: ≤1000A/5S
Temperature: -20~60℃
Dimension: 180*165*76(±1mm)
Weight: 4Kg
Packaging: Plastic case
Protection: PCM(Customized available)
Model NO.12.8V 10Ah LFP High Rate
Specification
Nominal Capacity: 10Ah
Operating Voltage: 8.4~14.5V
Charging current: ≤20A
MAX.Discharging current: ≤500A/5S
Temperature: -20~60℃
Dimension: 216*124*95.9(±1mm)
Weight: 2.5Kg
Packaging: Plastic case
Protection: PCM(Customized available)
Model NO. | 12.8V 10Ah LFP High Rate | 12.8V 20Ah LFP High Rate |
---|---|---|
Rated Capacity | 10Ah | 20Ah |
Operation Voltage | 12.8V | 12.8V |
Charging Current Max | 10A | 20A |
Discharge Current Max | 10A | 20A |
Energy | 128Wh | 256Wh |
Dimension(mm) | 216±1mm | 180±1mm |
Weight | 2.5kg | 4Kg |
Application: Widely used in agricultural machinery, tractors, automobiles, trucks, ships, diesel generators, forklifts, bulldozers and other construction machinery, fully replace lead-acid batteries, can also be used for emergency start, light and portable.
Charateristics: High-protection and long-life lithium battery, internal wide working temperature range and IP68 high protection level make it still usable in harsh environments, superior performance, certified by IEC, UN, UL, etc;The built-in protection system comes with multiple protections.Safe and reliable.
