Industry Battery

Product model of Industry Battery

14.4V 15Ah LFP Lithium Battery for Security System

14.4V 15Ah LFP Security System Battery

Specification
Nominal Capacity: 15Ah
Operating Voltage: 12~16.8V
Charging current: ≤10A
Discharging current: ≤10A
Temperature: -20~60℃
Dimension: 200*75*60mm(±3mm)
Weight: 1.2Kg
Packaging: PVC
Protection: BMS(Customized available)

12.8V 200Ah LFP Security System Battery

Model NO.12.8V 200Ah LFP

Specification
Nominal Capacity: 200Ah
Operating Voltage: 8.4~14.6V
Charging current: ≤30A
Discharging current: ≤30A
Temperature: -20~60℃
Dimension: 375*252*160mm(±3mm)
Weight: 23Kg
Packaging: SPCC Aluminum case
Protection: PCM/BMS(Customized available)

Product model table

Model NO.	Rated Capacity	Operation Voltage	Charging Current Max	Discharge Current Max	Energy	Dimension(mm)	Weight
Length	Width	Height
12.8V 200Ah LFP	200Ah	12.8V	30A	30A	2560Wh	375±3mm	252±3mm	160±3mm	23Kg
14.4V 15Ah LFP	15Ah	14.4V	10A	10A	216Wh	200±3mm	75±3mm	60±3mm	1.2Kg

Model NO.	12.8V 200Ah LFP	14.4V 15Ah LFP
Rated Capacity	200Ah	15Ah
Operation Voltage	12.8V	14.4V
Charging Current Max	30A	10A
Discharge Current Max	30A	10A
Energy	2560Wh	216Wh
Dimension(mm)	375±3mm	200±3mm
Weight	23Kg	1.2Kg

Contact Us

Characteristics and advantages of Industry Battery

Product Features

• The products are widely used in AGV handling robots and AGV trolleys, patrol robots, welcome robots, service robots, express sorting robots, etc. Its advantages are high automation, high safety, low maintenance costs, and a wider use environment, which can replace labor Complete some special tasks.

• Multiple safety management functions: overcharge protection, over discharge protection, over current protection, over temperature protection, short circuit protection.

• Intelligent management balance, accurate SOC power display.

• High power output, strong power, low internal resistance and low heat.

Safety And Reliability

• Adopt dedicated analog front-end acquisition IC and MCU to ensure stable operation of battery performance, safety and reliability.

• Use batteries that meet the requirements of vehicle regulations.

• Passed IEC62133, UL, UN38.3 certification.

What is the Difference Between Industrial Batteries and Regular

Super Long Life

• The initial performance of the battery is consistent, the charging and discharging dynamics are consistent, the attenuation trend is consistent, and the system is balanced.

• The cycle life of the product can reach more than 4000 times.

• Low power consumption and high energy density design, strong endurance.

1.Application OF industrial battery: It is suitable for AGV handling robots and AGV trolleys, patrol robots, usher robots, service robots, express sorting robots, and support power for medical equipment and other equipment.

2.Characteristic of heavy duty battery: Cells are strictly screened, have high degree of consistency, support high-rate charging, small size, light weight, long life, excellent capacity retention, wide operating temperature range, etc. The products have passed various strict tests and general national certification, ensure the safety performance of the battery.

3.What is the difference between industrial battery products and regular?

Industrial rechargeable batteries are often used for power use in industrial equipment. Industrial batteries and chargers have the characteristics of high capacity, long cycle, wide use temperature, high working voltage, and no memory effect. Conventional batteries tend to be used for civilian or commercial purposes, such as mobile phone batteries, energy storage batteries, etc. The battery performance requirements are not as high as those of industrial equipment, and they are widely used.

4.What are industrial lithium batteries used for?

Industrial batteries are used for industrial supporting equipment, or industrial equipment power use, such as forklift supporting batteries, AGV trolley power batteries, etc., suitable for various industrial environments, and have the characteristics of high cycle life, high capacity, and strong power.
