Electric Wheelchair Battery

Part number of electric wheelchair batteryelectric wheelchair battery:

25.2V 10Ah NCM Battery

Features of drive electric wheelchair battery:

• Power Lithuim-ion battery Pack
• Use in Electric wheelchair
• Protection IC,stable working
• Long running life, High stability, Low maintenance costs
• Small, Light, Easy to carry, Highly integrated
• ESD contact type with 8KV high voltage
• IP54 Rating
• Low-power consumption,Long standby time
• Portection with Overcharge / Overdischarge / Overcurrent / Short circuit / temperature protection to ensure safety while using
• RoHS eco-friendly design
• Pack approved by IEC62619/UN38.3 certification
• PCM & cell double protection to ensure the battery safety

Electric Wheelchair Battery Price

1.Specification drive electric wheelchair battery

Loading, please wait...
Model25.2V 10Ah NCM Battery
Model Capacity10Ah
Minimum Capacity (0.5C,A)9.8Ah
Rated Voltage25.2V
Max Charge Voltage29V
Cut-Off Voltage21V
Standard Charge And Discharge Current2A
Max Continuous Charge Current5A
Max Continuous Discharge Current15A
Weight (Approx. Includes Case)~2Kg
Loading, please wait...
Impedance (Max, At 1000Hz.)≤80mΩ
Electrostatic Requirements+/- 6KV
Charge Method (CC)2A(29.4VCut Off)
Charge Method (CV)29.4V(0.2ACut Off)
Operating Temperature Charging0℃~45℃
Operating Temperature Discharge-20℃~60℃
Operating Temperature Storage-20℃~45℃

2.Bock diagram electric wheelchair battery

The power wheelchair battery product adopts a hardware protection solution, same port input and output, supports single-cell voltage monitoring function, temperature monitoring function, current monitoring function, and equalization function to ensure stable performance, safety and long-term use of the electric wheelchair battery replacement product.

Drive Electric Wheelchair Battery

3.Outline Drawing electric wheelchair battery

The solution based on superior process technology, the product is small and exquisite, with large capacity, external Molex terminal, sealing process of glue, meeting IP54 requirements, suitable for most environments, actual size: 194mm*146mm*30mm, easy to install and replace.

Replacement Battery for Power Wheelchair

4.Electric Wheelchair Battery Types

Electric wheelchairs give users a better experience. Generally, lead-acid batteries or lithium batteries are used as power. Relatively speaking, lithium batteries have the advantages of higher capacity and better environmental protection and pollution-free cycle performance, and are more popular with users.

5.Electric Wheelchair Battery Replacement

Lead-acid batteries have small capacity, large volume and greater environmental pollution. The lithium battery has a larger capacity, a smaller volume, and is easy to install and disassemble. It can perfectly replace lead-acid batteries and seamlessly switch between use.
